Processor / System Bus

• Core Logic
  Intel® C621 Chipset
• Memory
  Total Slots : 12 (6-channel per CPU, 12 DIMM per CPU)
  Capacity : Maximum up to 1536GB RDIMM
  Memory Type :
  DDR4 2933/2666 RDIMM
  DDR4 2933/2666 LRDIMM
  Memory Size :
  128GB, 64GB, 32GB, 16GB RDIMM/LRDIMM
• Expansion Slots
  Total Slot : 5
  Slot Location 1 : PCI-E x16 (Gen3 X16 Link)
  Slot Location 2 : PCI-E x16 (Gen3 X16 Link)
  Slot Location 3 : PCI-E x16 (Gen3 X4 Link)
  Slot Location 4 : PCI-E x16 (Gen3 X16 Link)
  Slot Location 5 : PCI-E x16 (Gen3 X16 Link)
• Form Factor
  CEB (12"x10.9", 305mm x 277mm)
• Storage
  SATA Controller :
  Intel® C621
  8 x SATA3 6Gb/s ports + 1 x M.2 connector (SATA 6Gb/s & PCIe® Gen3 x4 link)
  SATA Controller :
  ASMedia® SATA 6Gb/s controller
  2 x SATA3 6Gb/s ports
• Networking
  2 x Intel® I210AT
• On Board I/O
  1 x USB 3.0 pin header
  1 x USB 2.0 pin header
  10 x Fan Header , 4pin
  1 x TPM header
  1 x Serial Port Header
  1 x VROC Key Header
  1 x PSU Power Connector (24-pin ATX power connector + 8-pin ATX 12V power connector)
  1 x Chassis Intruder
• Back I/O Ports
  2 x USB 3.2 Gen2 ports (1 x Type-A, 1 x Type-C)
  4 x USB 3.2 Gen1 ports
  2 x Gigabit LAN ports (RJ45)
  5 x Audio Jacks (7.1-channel HD Audio)
  1 x Optical S/PDIF output
• Management Solution
  WOL by PME,PXE
  ASUS Control Center Enterprise (Optional)
• Note
  * Suggest to use Intel Xeon W-3200 processors which support PCIe slots with full CPU links(64 lanes).
  Intel Xeon Scalable processors are supported, but there may be some limitations of CPU links(48 lanes).
