| Network Standard |
IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IPv4, IPv6 |
| Product Segment |
AC1500 enhanced AC performance : 600+867 Mbps |
| Coverage |
Large homes |
| Data Rate |
802.11a : 6,9,12,18,24,36,48,54 Mbps
802.11b : 1, 2, 5.5, 11 Mbps
802.11g : 6,9,12,18,24,36,48,54 Mbps
802.11n : up to 600 Mbps
802.11ac (5GHz) : up to 867 Mbps |
| Antenna |
Internal dBi antenna x 4 |
| Transmit/Receive |
MIMO technology
2.4 GHz 4 x 4
5 GHz 2 x 2 |
| Memory |
32 MB Flash
128 MB RAM |
| Operating Frequency |
2.4 GHz / 5 GHz |
| Encryption |
64-bit WEP, 128-bit WEP, WPA2-Personal, WPA-Personal, WPA-Enterprise , WPA2-Enterprise , WPS support |
| Management |
UPnP, DLNA, IGMP v1/v2/v3, DNS Proxy, DHCP, NTP Client, DDNS, Port Trigger, Port Forwarding, DMZ |
| VPN Support |
IPSec Pass-Through
PPTP Pass-Through
L2TP Pass-Through |
| WAN Connection Type |
Internet connection type : Automatic IP, Static IP, PPPoE(MPPE supported), PPTP, L2TP
WAN Bridge support |
| Ports |
RJ45 for 10/100/1000 BaseT for WAN x 1, RJ45 for 10/100/1000 BaseT for LAN x 3 |
| Features |
Router app
Smart Connect
Traditional QoS
AiProtection Classic
Parental Control
Guest Network : 2.4 GHz x 3, 5 GHz x 3
VPN server : PPTP Server, OpenVPN Server
VPN client : PPTP client, L2TP client, OpenVPN client
IPTV support
Beamforming
Traffic Monitor |
| Button |
WPS Button, Reset Button |
| LED Indicator |
Power x 1 |
| Power Supply |
AC Input : 110V~240V(50~60Hz)
DC Output : 12 V with max. 1 A current
DC Output : 12 V with max. 1 A current |
| OS Support |
Windows® 10
Windows® 8.1
Windows® 8 |
| Dimensions |
7 x 7 x 14 cm (WxDxH) |
| Weight |
257 g |
| Package Content |
Router(CD6R)
Node(CD6N)
RJ45
Adapter
QSG
Warranty Card |
